Precision. Control. Dynamics.
Founder is no ordinary loudspeaker. Every component, large and small, was scrutinized down to the tiniest detail. Every component has been thoroughly researched, designed, engineered, exclusively for Founder’s. New patent pending technologies were developed for the acoustic platform. The new cabinet platform is not just a stunning design, the unique shape and integrated structural bracing delivers acoustic performance that cannot be matched by traditional square boxes. By leaving no element unaddressed, Founder’s is so much more than the sum of its parts.
AL-MAC™ High-Frequency Driver
AL-MAG™ Midrange Driver
Beautiful Premium-Grade Finishes
Founder Series cabinets are offered in a variety of beautiful premium-grade finishes: Walnut and Black Walnut have a smooth satin finish with distinctive wood figuring. Our exclusive Midnight Cherry and Piano Black feature a luxurious hand-rubbed, high-gloss finish.
Ultra-High-Excursion CARBON-X Unibody Bass Driver
ADVANCED Shock-Mount™ Feet
ADVANCED Shock-Mount™ System
Cascade-Fusion Bracing
Cascade-Fusion Bracing inside Founder Series’ faceted cabinets increase rigidity and break up standing low-frequency waves. This delivers much tighter bass with greater clarity and accuracy. All bracing is extensively reinforced, making the cabinet into a monolith stronger than the sum of its parts. The inherent strength of the geometric cabinet profile distributes the load points across a larger cabinet area providing greater support and rigidity than can be achieved with traditional square cabinet geometry.
Specifications
- Type: 2-way standmount, ported enclosure
- Crossover: 2nd order electro-acoustic at 1.6kHz (tweeter/midbass)
- High Frequency Driver: 1" (25mm) AL-MAC™ Ceramic Dome with Oblate Spheroid Waveguide (OSW™) and Perforated Phase-Aligning (PPA™) Tweeter Lens, ferro-fluid damped / cooled
- Frequency Response On-Axis: ±2dB from 69 Hz - 23 kHz
- Frequency Response 30° Off-Axis: ±2dB from 69 Hz - 20 kHz
- Mid/Bass Frequency Driver: 6” (152mm) Ultra-High-Excursion AL-MAG™ Cone with Perforated Phase-Aligning (PPA™) Lens, Gen3 Active Ridge Technology (ART™) with Vertical Mounting System, Advanced SHOCKMOUNT™ Isolation, and a 1.5” high-temp multi-layered voice coil with ventilated Apical™ former
- Sensitivity (Room/Anechoic): 92 dB / 89 dB
- Low Frequency Extension: 41 Hz (DIN)
- Suitable Amplifier Power Range: 15 - 150 watts
- Maximum Input Power: 120 watts
- Impedance: Compatible with 8 ohms
- Finishes: Piano Black, Black Walnut, Midnight Cherry, Walnut
- Dimensions (H x W x D): 14.5” x 7.8” x 12.8” (36.8cm x 19.7cm x 32cm)
- Weight: 25 lbs (11.3 kg) each
Stand not included
